MC4-Compatible PV Connector (Male/Female, IP67)
Overview
The MC4-compatible PV connector is a key DC cabling component that links solar modules, strings and inverters. It uses a male/female plug-in design with dimensions compatible with the mainstream MC4 interface. Built with tin-plated copper contacts and a weather-resistant PPO/PC insulating housing, it offers IP67 protection and supports 1000V/1500V DC for 2.5mm², 4mm² and 6mm² solar cables. The snap-lock structure allows fast installation and requires a tool to unlock, reducing the risk of poor contact or accidental disconnection. It is widely used in residential rooftop, C&I distributed, utility-scale and energy storage DC-side wiring. OEM customization, multi-size kits and export-ready bulk packaging are available, making it a cost-effective choice for PV project cabling.
Get a Quote for This Product →MC4-Compatible PV Connector (Male/Female, IP67) - Features
IP67 Protection
When mated, the seals compress around the cable and interface, keeping out dust and withstanding temporary immersion for long-term outdoor use.
Tin-Plated Copper Contacts
Excellent conductivity and low contact resistance, with tin plating that resists oxidation and corrosion and reduces heat build-up over time.
Weather-Resistant Housing
The housing is made of UV-resistant, flame-retardant PPO/PC engineering plastic, suitable for high heat, severe cold and intense sunlight.
Anti-Disconnect Locking
Once snapped together, a dedicated tool is required to separate the connectors, reducing accidental unplugging and vibration-related loosening.
Wide Cable Compatibility
Fits 2.5mm², 4mm² and 6mm² (14/12/10 AWG) PV cables to meet different current requirements.
High Voltage Rating
Supports 1000V and 1500V DC systems, suitable for mainstream string-type PV plants and utility-scale projects.
OEM and Kit Supply
Male/female pairs, Y-branch connectors and extension cable assemblies are available, with custom logo, color and packaging options.
MC4-Compatible PV Connector (Male/Female, IP67) - Specifications
| Rated Voltage | 1000V DC / 1500V DC |
|---|---|
| Rated Current | 17.5A (1.5mm²) / 30A (2.5mm², 4mm²) / 35A (6mm²) (reference values, depending on cable and ambient temperature) |
| Cable Cross-Section | 2.5mm², 4mm², 6mm² (14/12/10 AWG) |
| Cable Outer Diameter | approx. 4.5–7.8mm (depending on seal size) |
| Test Voltage | 6kV AC for 1 minute (reference) |
| Contact Resistance | ≤0.5mΩ |
| Insulation Resistance | ≥500MΩ |
| Protection Degree | IP67 (when mated) |
| Operating Temperature | -40°C to +90°C |
| Flame Rating | UL94 V-0 (housing material) |
| Termination Method | Crimp type (matching crimping tool required) |
MC4-Compatible PV Connector (Male/Female, IP67) - Material & Structure Attributes
The key differences in this product category lie in material grade, anti-corrosion finish, and head structure. Together they determine durability in different environments, installation method, and grounding capability.
Contact Material
Pure copper (Cu-ETP) stamped contacts with high conductivity and good spring performance.
Surface Plating
Tin-plated contacts for better oxidation and corrosion resistance, with thicker plating available on request.
Housing Material
PPO/PC engineering plastic with UV resistance, aging resistance and flame retardancy for long-term outdoor use.
Sealing Structure
Silicone or EPDM seals provide dual sealing at the mating interface and the cable entry.
Locking Type
Snap-lock design that requires a dedicated tool to release.
Interface Type
Male (pin) / female (socket) pairing with a form factor compatible with the mainstream MC4 interface.
MC4-Compatible PV Connector (Male/Female, IP67) - Applications
Residential Rooftop PV
Connects modules and strings quickly and withstands long-term outdoor exposure in home and small rooftop systems.
C&I Distributed PV
Suitable for multi-string systems on factory and warehouse rooftops, balancing installation efficiency and cost.
Utility-Scale PV Plants
Fits 1500V DC systems for string combining and inverter connection in large solar farms.
Energy Storage DC Side
Used for DC cable connections between battery clusters and converters (current and voltage ratings must be verified).
Solar Pumping and Off-Grid Systems
Used for cabling in agricultural irrigation and remote-area off-grid solar systems.
PV Cable Assembly Manufacturing
Supplied as raw components for producing extension cables, Y-branch harnesses and inverter leads.
MC4-Compatible PV Connector (Male/Female, IP67) - Selection & Ordering
Confirm Cable Size
Check the cable cross-section (2.5/4/6mm²) and outer diameter first, then choose the matching connector and seal to prevent sealing failure.
Match Voltage and Current
Select according to 1000V or 1500V DC and string current, leaving a safety margin.
Match the Crimping Tool
Use the crimping tool and die designed for the connector. Crimp quality directly affects contact resistance and heat generation.
Use Matched Pairs
Use male and female connectors from the same supplier and batch. Mixing brands can cause contact and sealing problems.
One-Stop Supply
Connectors, crimping tools, release tools and cable assemblies can be supplied together.
MOQ and Customization
Sample orders are accepted. Please contact us for bulk MOQ and OEM options (logo, color, packaging).
MC4-Compatible PV Connector (Male/Female, IP67) - Quality & Delivery
Material Inspection
Incoming checks on contact copper, plating and housing plastic ensure consistent material quality.
Pre-Shipment Inspection
Batches are sampled for appearance, dimensions, mating force and seal installation, with quantity and packaging rechecked before shipment.
Testing Support
Test data can be provided on request, and third-party laboratory testing for electrical and environmental performance can be arranged (cost and lead time to be agreed).
Export Packaging
Moisture-proof bag, inner box and outer carton protect contacts from oxidation and housings from deformation in transit.
Lead Time and Shipping
In-stock sizes usually ship in 3–7 days and custom orders in about 15–25 days, by sea, air or international express (subject to order confirmation).
After-Sales Support
Retained batch samples and traceability records allow us to analyze quality issues and resolve them as agreed.
Suitable for Overseas Procurement
Supports sample orders, small-batch purchases, bulk orders, and OEM projects. Product packaging, labeling, cartoning, and export documentation can be arranged according to customer requirements.
MC4-Compatible PV Connector (Male/Female, IP67) - FAQ
Can you customize the logo, color or cable assemblies?
Yes. We support custom logos, colors and packaging, as well as OEM items such as Y-branch harnesses and extension cable assemblies. Please send your quantity and specification requirements.
What are the MOQ and lead time?
Sample orders are accepted, and bulk MOQ is available on inquiry. In-stock items ship in about 3–7 days and custom orders in about 15–25 days.
What crimping tool is required?
A matching crimping tool is required. We can supply crimping and release tools or advise based on the tools you already have.
What certifications do you have?
We can arrange third-party testing (such as TÜV or UL) at the customer’s request and provide material and test data. If your target market has mandatory certification requirements, please tell us when you inquire and we will assess feasibility.
Can they be mated with other brands’ MC4 connectors?
We do not recommend it. Tolerances, materials and locking structures differ between brands, and mixing may raise contact resistance, weaken sealing or cause heating. Use matched pairs from the same supplier and batch.
What are the rated voltage and current?
Rated voltage is 1000V/1500V DC and rated current is about 30A (2.5/4mm²) and 35A (6mm²). Actual current capacity depends on the cable and ambient temperature.
Which cable sizes are supported?
2mm², 4mm² and 6mm² (14/12/10 AWG) PV cables are supported. Please send the cable outer diameter so we can match the right seal.
Are your products original MC4 connectors?
Our products are MC4-compatible connectors with interface dimensions matching the mainstream MC4 standard. They are not original-brand products. MC4 is a third-party trademark used only to describe compatibility.
