PV Mid Clamp / End Clamp for Solar Panel Mounting
Overview
PV mid clamps secure two adjacent solar modules, while end clamps hold the outermost modules of an array. Together with rails and bolts, they are core fastening parts for rooftop, ground-mount and carport PV racking. Made from extruded 6005/6063 aluminum alloy with anodized finish, they offer good weather and corrosion resistance. They fit common module frame heights such as 30/35/40/45mm, come in silver or black, and support OEM customization for installers, distributors and racking manufacturers.
Get a Quote for This Product →PV Mid Clamp / End Clamp for Solar Panel Mounting - Features
High-Strength Aluminum Alloy
Extruded from 6005-T5/6063-T5 aluminum, balancing strength and light weight for long-term outdoor use
Anodized Corrosion Protection
Anodized surface resists weathering and corrosion, available in silver or black for a clean, uniform look
Wide Frame Compatibility
Fits common module frame heights such as 30/35/40/45mm, with custom sizes made to drawings
Fast and Easy Installation
Simple design locks in place with T-bolts or square nuts, reducing on-site labor and installation time
Anti-Slip Serrated Design
Optional serrated teeth or grooves improve grip and can assist module grounding continuity (on request)
OEM/ODM Supported
Length, hole position, color, logo and packaging can be customized to suit different markets and projects
PV Mid Clamp / End Clamp for Solar Panel Mounting - Specifications
| Product Type | Mid Clamp / End Clamp |
|---|---|
| Clamp Material | Aluminum Alloy 6005-T5 / 6063-T5 |
| Surface Treatment | Anodized (Silver / Black) |
| Module Frame Height | 30mm / 35mm / 40mm / 45mm (customizable) |
| Clamp Length | Typically 40–100mm (customizable) |
| Mid Clamp Module Gap | Approx. 20mm (customizable) |
| Matching Bolts | M8 stainless steel (SUS304/A2-70) T-bolt or hex bolt with square nut |
| Reference Tightening Torque | About 15–20 N·m (follow the module manufacturer’s manual) |
| Compatible Rails | PV aluminum rails, C-channel steel, T-slot rails |
| Customization | Made to drawings or samples, small-batch sampling supported |
| Packing | Carton packed by set or piece, export pallet packing available |
PV Mid Clamp / End Clamp for Solar Panel Mounting - Module Compatibility
Select compatible mid and end clamps based on solar module frame thickness, mounting rail design and fastening method to ensure proper fit and secure installation.
Solar Module Frame Thickness
Select the clamp height according to the actual aluminum frame thickness to avoid improper fit.
Clamp Installation Position
Mid clamps are used between adjacent modules, while end clamps are installed at the outer edges of the array.
Rail Compatibility
Confirm the rail slot profile, width, bolt size and fastening method to ensure compatibility.
Module Clamping Zone
The contact position and clamping area must follow the module manufacturer's installation instructions to avoid damaging the frame or glass.
Corrosion Protection
Select an appropriate surface finish for the operating environment and confirm the required coating or anodizing specifications.
Structural Load Requirements
Wind loads, snow loads, clamp quantity and installation positions should be determined by the applicable mounting-system design and project requirements, rather than appearance alone.
PV Mid Clamp / End Clamp for Solar Panel Mounting - Applications
Rooftop PV Systems
Used on metal, tile and flat roof racking to secure module frames
Ground-Mount Solar Plants
Used on ground racking and large PV arrays for bulk installation
Solar Carports and Canopies
Used to fix modules on carports, sunrooms and building-integrated PV projects
Commercial and Industrial Projects
Used for distributed PV systems on factories, warehouses and commercial roofs
Racking System Supply
Suitable as a standard or replacement part for racking makers, EPC contractors and distributors
PV Mid Clamp / End Clamp for Solar Panel Mounting - Selection & Ordering
Confirm Frame Height
Provide the module model or frame cross-section before ordering so the clamp height can be matched
Choose Mid or End Clamp
Mid clamps go between adjacent modules and end clamps at array ends; determine quantities by layout
Select Material and Color
Choose alloy grade, anodizing color and stainless bolt grade according to the installation environment
Send Drawings or Samples
For custom parts, send CAD drawings or samples and we will assess tooling, sampling and pricing
MOQ and Pricing
Trial orders and bulk orders accepted; price depends on model, quantity and surface treatment
RFQ Details
Please tell us specification, quantity, destination port, color, packing requirements and whether bolts are needed
PV Mid Clamp / End Clamp for Solar Panel Mounting - Quality & Delivery
Incoming and In-Process Inspection
Aluminum profile, dimensions, hole positions and anodized appearance are inspected, with batch traceability
Test Reports
Material, dimensional and salt spray test reports can be provided on request, and we can cooperate with third-party testing chosen by the customer
Export Documentation Support
We can assist with customs documents and certificates of origin; please state any destination-market certification requirements when inquiring
Protective Packing
Inner bags, cartons and pallets reduce scratches and moisture damage, suitable for sea freight and LCL shipments
Lead Time and Shipping
Stock and standard items ship quickly, custom items depend on tooling and production time; FOB, CIF and other terms available
Suitable for Overseas Procurement
Supports sample orders, small-batch purchases, bulk orders, and OEM projects. Product packaging, labeling, cartoning, and export documentation can be arranged according to customer requirements.
PV Mid Clamp / End Clamp for Solar Panel Mounting - FAQ
How are the products packed and shipped for export?
They are packed in inner bags and cartons, with pallets available. Sea freight, LCL and express samples are supported, with FOB, CIF and other terms.
What is your minimum order quantity?
Standard items support small trial orders, while custom items depend on tooling and production requirements. Contact us for a specific quote.
Can you provide test reports or certifications?
We can provide material, dimensional and salt spray reports on request and cooperate with third-party testing. If your market requires specific certification, please tell us in advance so we can assess feasibility.
Do you supply matching bolts and nuts?
Yes, we can supply complete sets with M8 T-bolts, hex bolts, square nuts and washers. Please state your rail model and required accessories when inquiring.
Can color, length and logo be customized?
Yes. Silver or black color, length, hole position, logo marking and packaging can be customized, depending on quantity and process.
Are the clamps made of aluminum or stainless steel?
The clamp body is anodized aluminum alloy, supplied with stainless steel bolts. Please ask us if you need an all-stainless option.
How do I choose the clamp height?
Clamp height must match the module frame height, commonly 30, 35, 40 or 45mm. Send the module model or frame drawing and we will help confirm.
What is the difference between a PV mid clamp and an end clamp?
A mid clamp sits between two adjacent modules and holds both frames, while an end clamp sits at the outer edge of the array and holds one module. They are normally used together.
